Pétrole et gaz À vendre

Air Ride Suspension • Air Brakes • Aluminum Wheels • 275/70R22.5 Tires • 90718 lb GVWR • Per Seller: 2019 Premier Coiled Tubing Rig Package Includes: *2020 Kenworth 12x6 Heavy Haul T/A Day Cab Truck Tractor* 2-3/8" Reel Trailer 24 •000ft Capacity w/PCS-130 Injector Head • Control Cabin * One-Piece Support Trailer w/Power Pack • Fuel Tank • Riser Skid • Hydraulic BOP Tilt Frame * Tridem Jeep * Tridem Booster *Lubricators (Located in E Texas)* Spare Reel & (2) Frames (Located in Midland • TX) 1NKDX4TX8LR373279 Kenworth Truck Tractor 7KF1P7268KA000109 Mertz Coil Tubing Trailer 5JYDF5331KED13362 Dorsey Support Trailer 7KF1P3637KA000045 Mertz Jeep Trailer 7KF1P1222KA000049 Mertz Booster Trailer

12 ft L x 12 ft W Substructure • Stairs • Safety Rails • Schramm Drawworks • 325 kW Generator • 250 kW Generator • Schaffer/Townsend 9 in 21000 psi Blowout Preventer • Triplex Pump • (1) Shale Shakers***Please see the specification documents below.***

- Engine: Hyundai; Power - 420PS/2000RPM; Cooling System - Water Cooling; - Drill Head Section: Reduction - Super gear - 5.1 to 1; Max. RPM - 1st 0-150rpm; 2nd 0-200rpm; Max. Torque - 1st 2600kg-M; 2nd 1300kg-M; - Feed System Head travel 1st: 11M; 2nd: Up- 1.4M • Down- 1.8M Pull-up capacity 120ton Pull-down capacity 9ton - Main Feed Winch Spool capacity 30M of 19㎜ cable Line pull 17 tons - Sub Feed Winch Spool capacity 25M of 16㎜ cable Line pull 9 tons - Winch Spool capacity 27M of 12㎜ cable Line pull 3 tons - Main Hydraulic System 3 pump open loop system Pump discharge rate H3V280DT (P1:280cc • P2:280cc) +Gear Pump(P3:10cc) - Sub Hydraulic System 4 pump open loop system - Pump discharge rate H3V63DT (P1:63cc • P2:63cc) +HSF30D (P3:30cc • P4:30cc) - Working Table Max. Casing diameter 12" Lod Handler Tilting Degree 90° Lod Handler Clamp Size Max 127mm - Crawler Base Crawler type Solar 220 (Motor : Solar 220) Ground pressure 0.5㎏/㎠

1.7 MMBTU/hr • 6100psi • 4M Length • Coil Diameter 20 inch •

Uniflux heater with low NOx natural gas burner • heat transfercoil • seespec sheet • See Attached Spec Sheet in listing

3 in Standpipe & Manifold • Hydraulic-Explorer 2 3000 496 kW Drawworks • Marathon MagnaMax 305 kW Generator • Control Technology 9 in 21000 psi Blowout Preventer • Triplex Pump • (1) Shale Shakers • Foremost Pipe Arm Catwalk • Rig Moves Quickly • Small Footprint • Capable of Operating Independently Without the Need for a Third Party Coring Unit

Out and Down Outriggers • Rear Outriggers • detroit series 60 6 Cylinder 12.7 L Diesel 500 hp Engine • 2002 US EPA Label • Positive Air Shutoff • 14188 Engine hrs • Allison 5-Speed Automatic Transmission • Differential Lock • Aluminum Wheels • 425/65R22.5 Front Tires • 12R22.5 Rear Tires • Air Assist Front Suspension • Rubber over Walking Beam Suspension • 292 in Wheelbase • Hydraulic System • kremco 2 Drum Drawworks • LEBUS Grooved • 72 ft stiff mast • 38X10 Draw Works • BOP Class II 7 in 3K • Mast hours 4977 • BOP Tubing • Tongs and Basket for Crane

4ft 11in. to 8ft 2in. • 486 tons of extracting force.

PTO Driven • Winch • Straight Down Outriggers • Cummins L9 350 6 Cylinder 8.9 L Diesel 350 hp Engine • 2017 US EPA Label • Requires Diesel Exhaust Fluid • Positive Air Shutoff • 4678 Engine hrs • Engine Brake • Eaton Fuller 10-Speed Manual Transmission • Differential Lock • 12350 lb Front Axle • 40000 lb Rears • 52350 lb GVWR • Air Ride Cab • Aluminum Wheels • 11R22.5 • Double Frame • Air Ride Suspension • 268 in Wheelbase • PTO • Farrow Engineered • Suspension drops when drawworks is engaged. Lube clamps. Hose reel -holds 120 Ft of 2 in high pressure line. Depth meter and weight indicator. Removable cabs with Cata-Dyne propane heaters. Methanol tanks plumb into lubricator. 39 in x 39.5 in Drum

2019 US EPA Label • CARB Compliant • Cat C9 6 Cylinder 9.3 L Diesel Engine

Paccar PX-9 6 Cylinder 8.9 L Diesel 350 hp Engine • 2013 US EPA Label • Requires Diesel Exhaust Fluid • Positive Air Shutoff • Webasto Engine Coolant Heater • 2957.9 Engine hrs • Air Conditioner • Cruise Control • Power Windows • Engine Brake • Allison 3000 Automatic Transmission • Differential Lock • 6623 kg Front Axle • 10433 kg Rears • Dana S23-170 Drive Axles • 5.25:1 Axle Ratio • 17055 kg GVWR • Aluminum Wheels • 12R22.5 Front Tires • 11R22.5 Rear Tires • Hendrickson Air Ride Suspension • 238 in Wheelbase • PTO • 23 ft x 102 in Bed • Winch • Pintle Hitch • C-Tech Model X-300 Injector • Hyd Scope Bed • Rear Hyd Outriggers • Fassi Micro M30A 13 Picker • Passenger Side Hyd Extend Racks

600 HP HPU • 5 •000 psi rated system • 130 gpm plumbed to 2 of 3 rails • variable displacement Parker pumps • 1500 gal. reservoir • PLC controlled • 480V 3 phase primary power • VFD motor control • outdoor rated • skid mounted • remote oil cooler • pump and motor group can be added to third rail for future expansion.

Cat C15 15.2 L Diesel 500 hp Engine • 2005 US EPA Label • Positive Air Shutoff • 1820.5 Engine hrs • Air Conditioner • Cruise Control • Power Windows • Engine Brake • Eaton Fuller 18-Speed Manual Transmission • Triple Differential Locks • Air Ride Cab • Aluminum Wheels • 425/65R22.5 Front Tires • 11R24.5 Rear Tires • Dual Steering Boxes • Double Frame • Airliner Air Ride Suspension • 302 in Wheelbase • PTO • Dual Fuel Tanks

Spare Stamps • Manual Sample Box • Signode Strapping Machine

Refurbished

Multi-Fuel Fueled • 3 Phase • 480 V Input • Stamford Generator • 2013 US EPA Label • John Deere 4045TF285 4 Cylinder 74 kW 4.5 L Diesel Engine • Stamford 60 kW Generator • Tri/A Trailer • Gooseneck • Electric Brakes

Multi-Fuel Fueled • 3 Phase • 480 V Input • Stamford Generator • 2013 US EPA Label • John Deere 4045TF285 4 Cylinder 74 kW 4.5 L Diesel Engine • Stamford 60 kW Generator • Tri/A Trailer • Gooseneck • Electric Brakes

Cat C15 15.2 L Diesel 475 hp Engine • 2006 US EPA Label • 1873.7 Engine hrs • Air Conditioner • Cruise Control • Engine Brake • Eaton Fuller RTLO-18918B 18-Speed Manual Transmission • Triple Differential Locks • 16000 lb Front Axle • 51999 lb Rears • Meritor RZ-166 Drive Axles • 4.30:1 Axle Ratio • 68000 lb GVWR • Air Ride Cab • 34 in Flat Top Sleeper Cab • Aluminum Wheels • 425/65R22.5 Front Tires • 11R24.5 Rear Tires • Airliner Air Ride Suspension • 289 in Wheelbase • PTO • Dual Fuel Tanks

Detroit series 60 6 Cylinder Diesel Engine • Detroit Series 60 • 300 kw Generator • Air Compressor • Triplex Pump • Detroit Series 60 • Allison Transmission • 7500 Liter Fuel Tank

PTO Driven • Straight Down Outriggers • Rear Outriggers • International MaxxForce 10 12.4 L Diesel Engine • 2012 US EPA Label • Webasto Engine Coolant Heater • 7105 Engine hrs • Air Conditioner • Cruise Control • Allison 3000RDS GEN4 Automated Transmission • 14000 lb Front Axle • 40000 lb Rears • 54000 lb GVWR • Air Ride Cab • 11R24.5 • Double Frame • Spring over Walking Beam Suspension • 620 mm Wheelbase • Dual PTO • Watson Hopper 1 Drum Drawworks

Open Operator Station • Yanmar 4 Cylinder Diesel Engine • 500 mm Rubber Tracks • 6800 mm Mast • A267619

6.6 m L x • ( 1 ) Crown Sheave Cluster • 80 mm Standpipe & Manifold • Deutz 96 kW Generator • 2010 Fassi Knuckle F22A22 Crane • 3 Stage Boom • A261124

Spring Suspension • 295/75R22.5 Tires • 68000 lb GVWR

Spring Suspension • 295/75R22.5 Tires • 68000 lb GVWR

Cat C15 6 Cylinder 14.9 L Diesel 475 hp Engine • Positive Air Shutoff • 0845.5 Engine hrs • Air Conditioner • Cruise Control • Power Windows • Engine Brake • Eaton Fuller RTLO-18918B 18-Speed Manual Transmission • Double Differential Locks • 14600 lb Front Axle • 46000 lb Rears • Meritor Drive Axles • 4.56:1 Axle Ratio • Air Ride Cab • Aluminum Wheels • 11R22.5 Front Tires • 11R22.5 Rear Tires • Airliner Air Ride Suspension • 228 in Wheelbase • Canuck C3000-HW-E • 80000 BTU Diesel-Fired Boiler • Dry Steam • Canuck C3000-HW-E • 3000 psi 20 gal /min Pump • Isuzu 4BG1T-B Engine • 3 Hose Reels w/ Trigger Wands • 2000 gal Water Supply Thermo King 22 ft x 96 in Wide x 96 in High Body • Curbside Door

Open Operator Station • 2004 US EPA Label • Deutz BF 6M 1013 C 6 Cylinder 221 hp 7.14 L Diesel Engine • 16 in Triple Grouser Track Shoes

2007 US EPA Label • CARB Compliant • Deutz DTC2015V08 V8 536 hp 15.8 L Diesel Engine • Containerized • Operation Manual

Air Ride Suspension • Air Brakes • Tail Roller • Kicker Rollers • Aluminum Outer Wheels • 275/70R22.5 Tires • 72727 kg GVWR

International DT466 7.6 L Diesel Engine • 2006 US EPA Label • 12337 Engine hrs • Air Conditioner • Cruise Control • Power Windows • Engine Brake • Eaton Fuller 10-Speed Manual Transmission • 10000 lb Front Axle • 19000 lb Rears • 29000 lb GVWR • Air Ride Cab • Flat Top Sleeper Cab • Aluminum Outer Wheels • 11R22.5 Front Tires • 11R22.5 Rear Tires • Air Ride Suspension • 230 in Wheelbase • PTO

Cat 6 Cylinder Diesel Engine

2 ft 0 in L x • Four-speed transmission • Cable drill • 496 m of NQ drill rods • Water pump and pump shack • 500gal diesel fuel tank with pump.

Enclosed Cab • Air Conditioner

Studded Top & Flanged Bottom • The trailer is included.

2011 US EPA Label • MTU 12V4000 12 Cylinder Diesel Engine • Allison 9823 Transmission • T/A Carrier • Air Ride
